Carbon Steel Ball

High carbon steel ball
  • International Equivalent:
  • 1084, SWRH82A, SWRH82B, C86D, 1.0616
  •  To Share:
  • inquiry
    • High carbon steel ball
    • High carbon steel ball
    • High carbon steel ball
    • High carbon steel ball
    • High carbon steel ball
Product information:

Balls of this type have the advance of being through hardened to HRC60 min and will take higher loads and provide longer life than case hardened balls.

High carbon steel ball
1. MaterialAISI1086/ C85/ 1.0616/ EN8-9/ Wks 1.1269
2. Size Range1mm-180mm
3. GradeG40-1000
4. Hardness60 min. HRC (Through-hardend)
5. Characteristic(a)Core-hardened
(b)Low resistance to corrosive attack
(c)Higher Load and longer life than low carbon steel ball
6. MagneticYes
7. ApplicationLow quality bearings, bicycles
8. Chemical composition

C%Si% Mn%Cr% Ni%Mo% P% S% Al% Cu%
min.0.830.10 0.50 ---------------------
max.0.880.30 0.80 0.15 0.20.050.0350.0350.010.25
9.PackingStandard: 10kg or 20kg per carton,1 ton per pallet or as customer required
10.Conditioning dry or oiled
11.Delivery timeStock within a short time or 35 days.
CHANGZHOU HUARI STEEL BALL CO., LTD.
Standard packing:
